CB (E6.1) 07/2017 Page 74/145
11.4 Confirming an active “set” alarm
Fixed value
08.03.2013 05:05:06
Initial view with overtemperature safety controller
alarm.
The buzzer sounds (if not deactivated previously).
Press the “Info” button.
Setpoint
Actual value
Temperature [°C]
37.0
39.2
CO2 [Vol.-%]
5.0
5.0
O2 [Vol.-%]
25.0
25.0
User
Info
Menu
Alarm acknowledgement
08.03.2013 05:05:06
Submenu “Alarms” for alarm acknowledgement.
../Home/Alarms
Safety controller overtemperature
Close Reset Home
Press the “Reset” button to confirm the alarm. If there is another active “set” alarm, you can also confirm it
with the “Reset” button. After confirming all active “set” alarms, the buzzer is off, and the initial view is
displayed.
As long as an alarm is still active, i.e. as long as the alarm cause is still valid, the alarm icon continues to
be displayed in the initial view.
