Instruction manual NSF VSI / VSI W / VSI T / VSI
TW About this machine
38065447002 en-US 13 / 101
The machine is available in different versions. The figure shows an example:
1
Blade guard ring
2
Blade
3
Blade cover
4
Product fixation device, vertical
5
Product holder complete with remnant holder
6
Carriage
7
Carriage guide
8
Display and operating unit with ON/OFF switch at the bottom of the machine housing
(optionally on top)
9
Stand, mobile
10
Lock at belt support
11
Identification plate
12
Conveyor
13
Light sensor
14
Gauge plate
15
Rear wall
16
Depositing arm
17
Chain frame with feed roller
18
Star knob screw on carriage foot
