Operation
Instruction manual NSF VSI / VSI W / VSI T / VSI
TW
60 / 101 38065447002 en-US
Press the scale icon on the right.
Scale function is activated. The scale
icon is displayed in the status bar. If this
function is deactivated, the tile target
weight is grayed out.
Enter target weight directly or change
value step by step using the Up/Down
keys and confirm.
Fig.58: Target weight parameter
Switching on the scale the following parameters are set:
– reference weight set to 8 g/mm
– anchor set to number of slices
– set target weight to the value that results from the current parameters
For machines with conveyor belt:
The shingling length currently set is longer than the weighing conveyor.
– Reduce shingling distance.
If it is not possible to reduce the shingling distance, a message is dis-
played.
Scale remains switched off.
Switching off the scale:
– The anchor set to number of slices or slice thickness will be deleted.
6.12 Ending slicing
To stop the slicing process, press <Execute>. Use the <OFF switch> only
in an emergency to stop the slicing process.
WARNING
Gauge plate!
Risk of crushing when gauge plate moves to zero position.
– Do not reach into area between gauge plate and carriage rear wall.
– Do not reach into area between gauge plate, carriage and product
holder.
– Do not reach into area between gauge plate and blade.
On the display and operating unit press <Execute>.
The drives will be switched off.
