Instruction manual NSF VSI / VSI W / VSI T / VSI
TW Maintenance
38065447002 en-US 85 / 101
Light sensor
Push the top of the light barrier into the
holder.
Fig.109: Light sensor
WARNING
Missing components!
The operator can only be protected from injuries and the machine
protected against damage if all the components of the machine are
assembled properly.
– Check if the machine is complete before it is re-started.
– Check if components are positioned correctly and firmly.
– Only use original Bizerba spare parts and accessories.
8.6 Service and maintenance
The entire machine must be thoroughly cleaned based on usage, but at least twice a day.
Product holder guide shaft
Lift pipe and shaft on table guide
Ball bearing
Ball bearing
Guide roller (6 units)
Carriage shaft
Fig.110: Lubricate
After every cleaning, lubricate positions 1 to 6 lightly with oil from the accessories kit.
Re-sharpen blade if necessary.
