Bizerba VSI330 F User Manual

Instruction manual NSF VSI / VSI W / VSI T / VSI
TW Maintenance
38065447002 en-US 79 / 101
Carriage
CAUTION!Risk of being crushed between
carriage and housing.
Tilt the carriage in the direction of the ar-
row.
Using handle, screw into place on the
carriage foot.
Fig.91: Tilt in carriage
Feeding carriage, 400mm carriage
CAUTION!Risk of injury at driver spikes.
Insert the product support plate into the
channel along the sliced product holder
guide and screw tight with the star grip
screw.
Fig.92: Feeding carriage
Product holder, 400mm carriage
CAUTION!Risk of jamming between
product holder and gauge plate.
Hold on to the handle on the product
holder, loosen the clamping device using
the lock lever and move it downwards.
Position the top of the product holder at
the relevant fixtures and screw tight with
the star grip screw.
Fig.93: Product holder
