55
2. Press button four times until PARALLEL is blinking and
press .
3. Press to select the parallel MODE.
4. Use the rotary knob to select the setting of OFF or ON and press
.
5. Press button one time until ROLE is blinking and press .
6. Use the rotary knob to set the master or slave and press .
Use the same procedure to set up MASTER, SLAVE A, SLAVE B,
or SLAVE C for the other power supplies.
7. Press several times to exit the menu setting.
Slave Unit
When a power supply is set up to be a slave unit, it will wait for the
master’s connection, as shown below.
If the master unit has found the slave unit, the slave unit will be
controlled by the master unit and the following will be displayed:
To Next Page
