7. Check the oil level of the compressor oil in the separator (7). Proceed
as follows:
Figure 47: Check the compressor oil level
− Pull out the dipstick (8) when cold and wipe it with a lint-free cloth
or absorbent paper.
− Then insert the dipstick (8) and pull it out again.
− Carry out a visual inspection of the dipstick (8). The compressor
oil must be between the MIN and MAX marks. If the level is near
MIN or below MIN, a corresponding quantity of compressor oil
must be topped up.
➢ The compressor oil must not exceed the MAX mark.
8. Check the fill level in the supply tank of the central lubrication unit. Top
it up if necessary.
Risk of injury from moving components.
The fan blade continues to turn after the machine has been switched off
and can lead to injuries.
− Never reach into running devices.
− Before working at danger points, wait for running components to come
to a standstill and for residual energy to dissipate.
