BMS alpha CR - Work Operation Prep: Cooling Unit and Filter

Work mode
7
Prepare work operation
7.5
91
9. Check and clean the cooling unit (9). Remove the air filter by pulling it
up.
Figure 48: Cooling unit
➢ The air filter consists of a metal stand which is attached to the base
plate with magnets. The filter cover should be cleaned regularly.
➢ If you use the option filter hoods (10), the cooling unit (9) will not
become so dirty. An inspection is always necessary on a regular
basis.
