Operation in working mode
Figure 50: Filling the mixing and delivery vessel (feeder)
1. Open the cover (3) of the filling dome (2) as far as it will go.
2. Fold the hopper (4) onto the filling dome (2) of the mixing and delivery
vessel (1).
➢ The toothing of the hopper (4) is used to easily tear open bagged
material.
3. Switch on the mixing unit using the two-position switch.
4. Pull the "Raise/lower feeder" lever horizontally out of its latch and swivel
it downwards. The feeder is lowered for filling.
5. Fill the feeder with material (sand, gravel, etc.) up to below the grid.
This corresponds approximately to one vessel filling.
The feeder is suitable only for filling with sand or gravel. You must not add
any binding agent or water to the feeder.
There is a risk of heavy soiling. Cleaning is only possible with great effort.
A dirty feeder can have a too high total weight. The function can be
impaired (up to non-functioning!).
6. Pull the "Raise/lower feeder" lever horizontally out of its locking device
and swivel it upwards until the material slides into the mixing and
delivery vessel (1).
