BONFIGLIOLI Active Cube User Manual

Status word
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Bit
0
Ready to switch on
1
Switched on
2
Operation enabled
3
Fault
4
Voltage enabled
5
Quick stop (Low active)
6
Switch on disabled
7
Warning
8
-
9
Remote
10
Target reached
11
Internal limit active
12
-
13
-
14
-
15
Warning 2
If operation mode “Control via remote contacts” is used, controller release must be
turned on at STOA (Terminal X210A.3) and STOB (Terminal X210B.2) and
Bit 0 of the
control word must be set in order to be able to start the drive.
Operation modes “Control via contracts” and “Control via remote contacts” only su
p-
port modes of operation = “velocity mode”.
ACTIVE CUBE frequency inverters support an external 24 V power supply for the fre-
quency inverter control electronics. Even when mains voltage is disconnected, co
m-
munication between the controller (PLC) and the frequency inverter is still possible.
Bit 4 “Power supply –
enabled” of the status word shows the current mains power
supply status:
Bit 4 “Power supply – enabled” = 0
signals “No mains voltage”, starting of drive not
possible.
Bit 4 “Power supply – enabled” = 1 signals “Mains voltage on”, drive ready for star
t-
ing.
10/13
ACU Modbus/TCP 65
