Status word:
The status word indicates the current operating state.
Status word
State
Bit 6
Bit 5
Bit 3
Bit 2
Bit 1
Bit 0
Switch on
disabled
Quick
stop
(Low
active)
Fault
Operation
enabled
Switched
on
Ready to
switch on
Switch on disabled
1
X
0
0
0
0
Ready to switch on
0
1
0
0
0
1
Switched on
0
1
0
0
1
1
Operation enabled
0
1
0
1
1
1
Quick stop active
0
0
0
1
1
1
Fault reaction active
0
X
1
1
1
1
Fault
0
X
1
0
0
0
“X” means any value.
Bit 7 “Warning” can be set at any time. It reports a device-internal warning. The
cause of the warning is evaluated by reading the warning status with parameter
Warnings 270.
Bit 9 “Remote” is set if the operation mode is set to “Control via state machine” (Lo-
cal/Remote 412 = 1) and controller release is turned on.
Bit 10 “Target reached” is set when the specified reference value is reached.
In configurations without Motion Control (parameter Configuration 30
≠ x40) “Target
reached” refers to the reference speed from OUT-PZD2
. In the special case of power
failure regulation, the bit is also set when the power failure regulation reaches the
frequency 0 Hz (see frequency inverter operating instructions).
For
"Target reached“, there is a hysteresis (tolerance range) which can be set via the
parameter Max. control deviation 549 see frequency inverter Operating Instructions).
Bit 11 “Internal limit value active” indicates that an internal limit is active. This
may be the current limit, the torque limit or the overvoltage control. All functions will
result in the reference value being left or not reached.
Bit 15 “Warning 2” signals a critical operating state which will result in a fault switch-
off of the frequency inverter within a short time. This bit is set if there is a delayed
warning relating to the motor temperature, heat sink/inside temperature, Ixt monito
r-
ing or mains phase failure.
10/13
ACU Modbus/TCP 71
