4-3
Bosch Security Systems 09/11 BLCC500I
Solution 16i
Installation Manual Programming Overview
4) The system will display the curent text. The curent
cursor position is indicated by the ashing
character. To move the cursor, use the left and
right arrow keys.
5) Enter the required text and then press [OK] to save
when nished.
The following additional special characters are
available by scrolling using the up and down arrow
keys. + - @ # $ “ & % * : ( ) / < > =
P RO GR AMM IN G T EL EP H ON E N U MB ER S
To program, select primary telephone number under
[MENU] 5-1-1 then enter the digits of the telephone
number and press the [OK] key to save. Use the up and
down arrow keys to program special characters (•, # and
Pause).
If the number is longer than can t on the keypad display
then you can use the [] and [] to scroll left and right to
view the entire number. It is also possible to edit a single
digit of the number by moving the cursor to the location
with the [] and [] keys.
974170
Figure 35: Telephone Number Programming Display
Key Characters Assigned To Each Numeric Key
0 to 9 Enter the Digits 0 to 9
Scroll Up through entire character list 0 - 9 • #
, comma = 2 second pause
Move to left or right one character position
OFF Clear from cursor position to end of line
Table 16: Phone Number Programming
To save programming changes, press [OK], else press
[MENU] to exit without saving.
P RO GR AMM IN G LI ST O P TI ON S
Enter the location (Menu) number to be programmed
followed by the [OK] key.
When prompted enter the number of the Zone, User, Area,
Output or Keypad to program then press the [OK] key.
Enter the required data and then press the [OK] key to
nish. Press [MENU] at any time to exit without saving.
Zn=3
The display will ash promting you to enter the
required data value.
d=01
Figure 36: List Option Programming Display
P RO GR AMM IN G T HE C LOC K
Clock programming requires the following information
to be entered, dd mm yy hh mm. To accept the currently
programmed data for any eld, simply press the [] to
move to the next field.
Enter location 7-1-0 followed by the [OK] key. The keypad
will display the currently programmed day of the month.
To change, enter the new day of the month. The system
will automatically move to the month eld.
dd=1q
To change, enter the new month of the year. The system
will automatically move to the year eld.
MM=05
To change, enter the new year. The system will
automatically move to the hour eld.
yy=07
To change, enter the hour of the day in 24hr format. The
system will automatically move to the minute eld.
To change, enter the minute of the hour followed by the
[OK] key to exit.
Pressing OK on any eld will accept all currently
programmed date and time values. Time is
programmed in 24 hr format.
