Bosch Solution 16i Installation Manual

8-2
Bosch Security Systems 09/11 BLCC500I
Solution 16i  Installation Manual  Output Programming
is On
The keypad will display the following when output 3
has a connection trouble (output device is missing).
cOnLSt
The keypad will display the following when output 3
has an overload condition.
OvLOAd
4) Press [OK] to exit.
Outputs > Commands > On-Off
Turn Output On/O

-

-

MENU 4-0-1
This menu allows you to manually control the system
outputs that have been programmed by your installer.
Outputs can be programmed to control sirens, strobe
lights, outside lighting, pool pumps, watering systems etc.
1) Enter your PIN + [MENU].
2) Enter [4] + [0] + [1] + [OK].
The keypad will ash the Op= prompt. Any output(s)
which are currently on will also be displayed.
Op=
1 3
If your system is congured for multiple areas the area
Icon for the current area will also be displayed.
3) Enter the output number + [OK] to toggle the output
on or o.
Repeat step 3 for any additional outputs that you
need to control.
4) Press [OK] to exit.
O UT PU T PR OP ER T IE S
Outputs > Properties > OPnAME
Output Name

-

MENU 4-1-0
O u t p u t 1 N a m e
This menu allows the master user to program name of
each Output (Up to 16 characters). Use the [←] and [→]
keys to move the cursor position left and right to view the
zone name.
The text programming procedure is very similar to that of
most mobile phones. Refer the Programming Text section
on page 4-2 for more details.
Output names are stored with associated events in the
system’s history log. This enables accurate auditing of
events at a later time if required. Names are also used
when reporting alarms and turning an area on and o in
SMS and other text based reporting formats.
Each output has a default name which can be changed if
desired. The default names are as follows.
DEFAULT OUTPUT NAME S
Output Number Default Name
1 E ternAl Siren
2 strObe
3
smOke sensOr
4 InternAl Siren
5 Output 5 NAme
6 Output 6 NAme
7 Output 7 NAme
8 Output 8 NAme
Table 28: Default Output Names
Outputs 5 to 8 are available when an optional output
expander is tted. Discuss this feature with your installer.
1) Enter your Installer PIN or Master PIN + [MENU].
2) Enter [4] + [1] + [0] + [OK].
The keypad will ash the Op = prompt.
Op=
3) Enter the output number (1 to 8) you want to
program, then press [OK].
StrObe
