7-13
Bosch Security Systems 09/11 BLCC500I
Solution 16i
Installation Manual Input Programming
Inputs > PGM Input > L350
Input Type
MENU 3-5-0
(*** System Wide Parameter ***)
0 0
00 = Disabled
01 = Latching - On/O (RF Relay)
02 = Momentary - On/O (RF Relay)
03 = Digiex RF On/O
04 = Bosch Serial RF Receiver
05 = Crow Serial RF Receiver
06 = NESS Serial RF Receiver
07 = Inovonics Serial RF Receiver
08 = Secure Wireless RF Receiver
This menu option is used to congure the systems
programmable input terminal. Various devices can be
connected including keyswitches of radio controlled relays
etc. When RF zones are required you need to connect the
RF receiver to this input
Connect keyswitch between Input terminal and GND.
See Wiring Diagrams in Section 3 for various connection
diagrams.
1) Enter your Installer PIN + [MENU].
2) Enter [3] + [5] + [0] + [OK]. The keypad will display
the current input type (Default = 0 Disabled).
d= 0
3) Use the up and down arrows to select the required
Input Device Type then press [OK] to save and exit
or press [MENU] to exit without saving.
i
Note
The Latching and Momentary On/O modes are
active low, and when triggered, they will
automatically force arm the area.
Inputs > Tamper Inputs > L360
Tamper Options
MENU 3-6-0
1 Display Panel Tamper Y
2 Report Panel Tamper Y
3 Audible Panel Tamper Y
4 Display Expander Tamper N
5 Report Expander Tamper N
6 Audible Expander Tamper N
7 Reserved N
8 Reserved N
This menu programs how the various system tamper
inputs behave when faulted. These dedicated tamper
inputs are active 24 hours a day when enabled.
1) Enter your Installer PIN + [MENU].
2) Enter [3] + [6] + [0] + [OK]. The keypad will display
the current tamper options.
-Bit-
1 2 3
3) Use the numeric keys [1] to [8] to toggle on or o
the option required.
4) Repeat Step 3 until all options are programmed as
required, then press [OK] to save and exit or press
[MENU] to exit without saving.
Display Cabinet Tamper
Setting this option allows the keypad to display a trouble
condition when the tamper circuit that monitors the
systems cabinet is faulted. The trouble condition will
clear when the tamper circuit has restored.
Report Cabinet Tamper
Setting this option allows the panel to send a Cabinet
Tamper report when the cabinet tamper circuit is faulted.
A Cabinet Tamper Restore report will be sent when the
tamper circuit has restored.
Audible Cabinet Tamper
Setting this option will cause the panel to sound the
sirens when the cabinet tamper circuit is faulted.
Display Expander Tamper
Setting this option causes the system to display tamper
events which have occured on peripheral modules.
Report Expander Tamper
Setting this option enables peripheral tamper reporting.
Audible Expander Tamper
Setting this option causes the system to trigger an
audible alarm when a peripheral tamper is triggered.
