Solution 16i  Installation Manual  Input Programming
Inputs > RF Zone > L331
Delete RF Device

MENU 3-3-1
This menu allows you to delete an RF device .
1) Enter your Installer PIN + [MENU].
2) Enter [3] + [3] + [1] + [OK], then enter the zone
number required press [OK]. The keypad will
display the rst 6 digits of the current RF ID
number.
007407
3) Press [OK] to DELETE the RF device and exit or press
[MENU] to exit without deleting.
Inputs > RF Zone > L332
Test RF Device

MENU 3-3-2
This menu allows you to test just how good the current
position is for an RF device. Enter the command and you
will be presented with a list of RF zones in the current area
that are available for test. Use the arrow keys to highlight
the zone to test and press OK. At any time press menu to
exit.
1) Enter your Installer PIN + [MENU].
2) Enter [3] + [3] + [2] + [OK], then enter the zone
number required and press [OK].
triger
3) Once a signal is received the following information
will be displayed.
gOOd
Signal can = Good, Average or Move (Relocate)
G LOB AL I NP UT O PT IO N S
Inputs > Global Input Options > L340
EOL Value

MENU 3-4-0
(*** System Wide Parameter ***)
0 5
00 = No EOL
01 = 1K0 06 = 4K7 11 = 6K8 Alarm + 2K2 Tamper
02 = 1K5 07 = 5K6 12 = 10K Alarm + 10K Tamper
03 = 2K2 08 = 6K8 13 = 22K
04 = 2K7 09 = 8K1 14 = 3K3 Alarm + 6K8 Tamper
05 = 3K3 10 = 10K 15 = 3K3//6K8 Split EOL
This menu programs the End Of Line resistor (EOL) value
that is global for all hard-wired zones including zones on
the Zone Expander Module. Only one EOL Value can be
programmed.
Setting the EOL Value to type 0 to 14 will congure the
system as 8 hardwired zones . Additional zones via
optional zone expander boards will start on zone 9.
Setting the EOL as type 15 will congure the system as 16
hardwired zones.
1) Enter your Installer PIN + [MENU].
2) Enter [3] + [4] + [0] + [OK]. The keypad will display
the current EOL value (Default = 5).
d= 5
3) Use the numeric keys to enter the EOL Value you
require, then press [OK] to save and exit or press
[MENU] to exit without saving.
