Bosch Solution 16i Installation Manual

7-4
Bosch Security Systems 09/11 BLCC500I
Solution 16i  Installation Manual  Input Programming
ZO NE D E FAU LT TA BL E
The table below lists the default values for all zone parameters in the Solution 16i. By default, zones 5 to 16 are set as
Instant zones. Zones marked as Not Used do not require EOL resistors to be tted.
Programming Option Zone 1 Zone 2 Zone 3 Zone 4 Zones 5 to 16
Zone Name Zone 1 Zone 2 Zone 3 Zone 4 Zone 5 - Zone 16
Zone Type 1 = Delay 1 5 = Handover 5 = Handover 5 = Handover 3 = Instant
Area Assignment 1 1 1 1 1
Pulse Count 0 0 0 0 0
Pulse Count Time (Sec’s) 120 120 120 120 120
Access Group 0 0 0 0 0
Report Route 2 2 2 2 2
Reporting Options
Lockout Dialler Y Y Y Y Y
Report Alarm Y Y Y Y Y
Report Alarm Restore Y Y Y Y Y
Report Trouble Y Y Y Y Y
Report Trouble Restore Y Y Y Y Y
Report Bypass Y Y Y Y Y
Report Bypass Restore Y Y Y Y Y
Delay Report N N N N N
Zone Options
Lockout Siren Y Y Y Y Y
Silent Alarm N N N N N
Inverted Seal N N N N N
Bypass Allowed Y Y Y Y Y
Sensor Watch N N N N N
Armed When Part On Y Y Y Y Y
Reserved N N N N N
Test On Exit N Y Y Y Y
Table 26: Zone Defaults
ZO NE P R OP ER T IE S
Inputs > Zone Properties > ZnnAME
Zone Name

-

MENU 3-1-0
Z o n e 1 N a m e
This menu allows the master user to program name of
each zone (Up to 16 characters). Use the [←] and [→] keys
to move the cursor position left and right to view the zone
name.
The text programming procedure is very similar to that of
most mobile phones. Refer the Programming Text section
on page 10 for more details.
Zone names are stored with associated events in the
system’s history log. This enables accurate auditing of
events at a later time if required. Names are also used
when reporting alarms and turning an area on and o in
SMS and other text based reporting formats.
Each zone has a default name which can be changed if
desired. The default names are as follows.
DEFAULT ZON E N AMES
Zone Number Default Name
1 ZOne 1
2 ZOne 2
↓ ↓
16 ZOne 16
Table 27: Default Zone Names
1) Enter your Installer PIN or Master PIN + [MENU].
2) Enter [3] + [1] + [0] + [OK].
The keypad will display the Zn = prompt.
Zn=
3) Enter the zone number you want to program, then
press [OK].
The keypad will display the current Zone Name.
