Page #79 background imageLoading...
Page #79 background image
8-1
Bosch Security Systems 09/11 BLCC500I
S E C T IO N 8
Output Programming
T
he Solution 16i is capable of controlling up to 8 outputs.
The rst 4 outputs are on the main control board and
an additional 4 outputs are provided using an output
expander module. Each output can have its own unique
name up to 16 characters to identify it on the system for
display and reporting purposes.
Under the commands menu you are able to view the
status of any output and to change its on/o condition. In
the case of latching output types, you will be required to
reset the output manually using these commands.
Outputs are programmed using an event type. First select
the event type that will cause the output to trigger. Then
select the polarity of the event, if it is low and goes high or
high and goes low. If the event is pulsing or one shot type,
the time parameter must also be programmed to dene
the time of the pulse.
Event Assignment, this is extremely important parameter
and has a dierent meaning depending on the event type
selected. For example, event type “24 - Area Part On the
event assignment selects the Area that is armed in part on
for the output to trigger. If you set the event assignment
to 1, then it will correspond to area 1 and so on, setting
it to zero means all areas. See the event type table for
more detail on the relationship of event type to event
assignment.
Outputs 1 and 2 are special outputs that can be congured
as horn speaker polarity types and are monitored to
report a device connection trouble. Output 4 is a dry
relay contact which has a optional jumper that allows you
to switch positive or negative without the need to add
additional wiring.
The outputs are all protected and will shut down
individually under overload conditions. A report will be
generated and a displayed on the keypad to indicate the
trouble condition.
O UT PU T CO MM AN DS
Outputs > Commands > StAtus
Output Status
-
-
-
MENU 4-0-0
This menu allows you to view the the current status of
each output.
1) Enter your PIN + [MENU].
2) Enter [4] + [0] + [0] + [OK].
The keypad will ash the Op = prompt.
OP=
3) Enter the output number you want to view, then
press [OK].
The keypad will now display the status of the selected
output.
There are 4 posible states.
iS OFF - output is OFF,
iS On - Output is ON and
cOnLSt - Connection Trouble.
OvLOAd - Connection Overload.
If connection trouble or connection overload is shown
there may be a problem with an output device on the
system. In this case you should contact your installer
for further information.
The keypad will display the following when output 3
is OFF.
is Off
The keypad will display the following when output 2
is ON.
