SmartControl™ Meter & TouchPoint™ 11 9E-926
Operation Instructions
Table 1: LED Status Indicator, Color Patterns, Rotary Parlor
Function TouchPoint SmartControl Comments
Left
Indicator
Right
Indicator
Left Indica-
tor (Yellow)
Right Indi-
cator (Red)
Detached without an er-
ror or being manually de-
tached
White –
On continuously
White –
On continuously
On continuously This indicates a good
milking for the cow in
this stall. The white
LEDs will turn off before
the next cow is milked
in this stall.
Attached and in Automatic
Detach Mode with no milk
ow
Green -
Flashing
Green -
Flashing
On continuously
Attached and in Automatic
Detach Mode with milk
ow
Green –
On continuously
Green –
On continuously
Off continuously
Attached and in Manual
Mode with no milk ow
Yellow -
Flashes twice
with pause
Yellow -
Flashes twice
with pause
On
continuously
On continuously
Attached and in Manual
Mode with milk ow
Yellow –
On continuously
Yellow –
On continuously
On
continuously
Off continuously
Detached at Maximum
Milking Time
Red -
High speed
ashing
Red -
High speed
ashing
On for .1 sec-
ond and off .1
second
Flashing indicates that
the milking of this cow
was not normal and
may require the milk-
er’s attention.
Detached manually by
milker
Detached at the end of the
Let Down Delay
Red and blue -
High speed ash-
ing
Red and blue
- High speed
ashing
On for .1 sec-
ond and off .1
second
Flashing indicates that
the milking of this cow
was not normal and re-
quires the milker’s at-
tention.
Detached automatically
with production below a
settable threshold
Cows entering parlor Violet -
Turns violet as
cows are as-
signed to this
stall. If there is
no cow assigned
to that stall the
LED indicator will
not be turned on.
Violet -
Turns violet as
cows are as-
signed to this
stall. If there
is no cow as-
signed to that
stall the LED in-
dicator will not
be turned on.
When the stall goes
over the bridge area
the indicators are
turned off. Then as the
cows enter the parlor
the TouchPoint V indi-
cators turn violet.
Wash Mode Flashes dark blue
rapidly three
times with a long
pause in between
Flashes dark
blue rapidly
three times with
a long pause in
between
Flashes rapidly
three times with
a long pause in
between
