Tools
Diagnostics
Sensor Conditions
This diagnostic detects the sensor conditions for ribbon motion, door, cutter,
leading (edge), diecut, tapeout, wiper, center and tear bar.
Conditions are:
•
BL
(blocked)
•
Clos
(closed) or
Open
•
Hom
(home position)
•
Eng
(engaged)
•
UnB
(unblocked)
To view the PEB settings:
1. Access Diagnostic mode (see “Enter Diagnostic Mode” on page 3-17).
2. Press T to scroll to Sensor Conditions, then press . The sensor settings
display results for the following:
3. Press W repeatedly to exit to the main menu or to return to the Sensor
Conditions menu.
RibbonMotion
BL
Door
Clos/Open
Cutter
Hom
Leading
BL
Diecut
BL
TapeOut
BL
Wiper
Eng
Center
BL
TearBar
UnB
