BBP
®
33 Sign & Label Printer
User’s Manual
3-21
Tools
Diagnostics
USB Test
The USB test verifies that the USB ports are active. The tests can be performed
with a flash drive or a type-B cable.
USB Flash Drive Test
To perform a USB test:
1. Access Diagnostic mode (see “Enter Diagnostic Mode” on page 3-17).
2. Press S or T to go to USB Test, then press to select the test.
3. Press to start the test.
4. Insert a USB flash drive into the Lower USB port. The display indicates
DSK2: attached.
5. Remove the USB flash drive. The display indicates DSK2: removed.
6. Repeat steps 4 and 5 for the Upper USB port.
7. When done, press
to exit the test.
USB Type-B Cable Test
To perform a USB test with a type-B cable:
1. Access Diagnostic mode (see “Enter Diagnostic Mode” on page 3-17).
2. Press S or T to go to USB Test, then press to select the test. The USB
Test Status screen displays.
3. Insert a USB type-B cable from the Lower Host port to the Function port.
The display indicates LPT1: attached.
4. Remove the USB type-B cable. The display indicates LPT1: removed.
5. Repeat Steps 3 and 4 for the
Upper Host port.
6. When done, press
to exit the test.
