BBP
®
33 Sign & Label Printer
User’s Manual
A-11
DPL Supported Commands
Objects
Polygon
Polygons are created by defining the positions of
corners, specifying a number of data points that
represent the vertices of the object, which can range
from a simple line (two points), or a triangle (three
points), to any free-form outline.
1 X 11 ppp rrrr cccc P ppp bbbb rrrr cccc rrrr
cccc ... <CR>
where:
1 = Rotation (must be 1)
001 = Fixed Value
X = Graphic field ID
0001 = Fixed Value
1 = Multiplier (must be 1)
rrrr = Row of Point 2
1 = Multiplier (must be 1)
cccc = Column of Point 2
ppp = Fill Pattern #
rrrr = Row of Point 3
rrrr = Row of Point 1
cccc = Column of Point 3
cccc = Column of Point 1
… = Additional Points
P = Polygon ID (Fixed Value)
<CR> = Termination Character
Object Descriptions DPL
