Step 5. Install the Ribbon Cartridge
1. Remove cartridge from the bag. Avoid
touching or creasing the ribbon.
Ribbon
Cartridge
2. Remove any ribbon slack by rotating take-up
spool end counter-clockwise.
3. Slide ribbon cartridge firmly into printer.
(Locking lever must be in unlock position –
see below.)
4. Push the locking lever towards the back
of the printer to close the print head and
lock the ribbon cartridge in place.
²
±
Locking
Lever
Step 6. Remove a Marker Roll
1. Cut off printed labels with the cutter
lever.
2. Open the roll door.
3. Slide the locking lever to the unlock
position.
4. Back the markers out of the material
guide slots.
To Next Page
