Brielmaier Motormäher GmbH Start-up | 4
BA Motor mower S250 (Version 2021/09) 53
Fitting spiked rollers
Proceed as follows to fit the spiked rollers:
a) Fit the spiked roller onto the wheel axle.
NOTE
It becomes easier if you take a centring bolt, screw it into one of the 5
threads and push the wheel on it.
b) Insert all five screws (1) and tighten with a torque spanner.
For the tightening torque, see chapter
Technical data
[}101].
c) Carry out the steps on both sides.
ð The wheel has been changed.
