brielmaier S250 - Page 52

4 | Start-up Brielmaier Motormäher GmbH
52 BA Motor mower S250 (Version 2021/09)
Removing twin wheels
The twin wheels are removed as follows:
1
a) Turn the wheel lock handle (1) anti-clockwise and release the
wheel lock.
2
3
b) Remove the outer wheel (2) from the adapter flange (3).
4
5
c) Loosen all five screws (4) on the adapter flange (5) and remove the
adapter flange.
6
7
d) Attach the adapter flange (6) to the outer wheel (7).
8
e) Fit the wheel lock (8) on the outer wheel and tighten it clockwise.
For the tightening torque, see chapter Technical data [}101].
9
10
f) Remove the inner wheel (9) from the wheel axle (10).
