Brother DCP-8065DN Servise Manual

App. 4-51 Confidential
WSW47
(Switching between high- and full-speed USB)
Selector
No.
Function Setting and Specifications
1
Handling paper at the
occurrence of a paper feed
timing error (Not used.)
0: Eject paper w/o print 1: Print on the current
paper
2 Not used.
3
4
Delay of FAX line
disconnection when switching
to the pseudo-ringing external
telephone (Not used.)
No. 3 4
0 0 : 200 ms
0 1 : 400 ms
1 0 : 700 ms
1 1 : 1000 ms
5
Disable the ringer of external
telephone at non-ring reception
(Not used.)
0: No 1: Yes
6 Not used.
7
Disable the ringer of external
telephone with CAR signal
when caller ID service is
available (Not used.)
0: No 1: Yes
8
Switching between high-speed
USB and full-speed USB
0: Auto switching between 1: Fixed to full-speed
high-speed USB (ver. 2.0) USB (ver. 1.1)
and full-speed USB (ver. 1.1)
NOTE: Selector 1 is applicable only to models equipped with flat-bed scanners.
NOTE: Selectors 3 and 4 are applicable only to models supporting pseudo-ringing of a connected
external telephone.
- Selector 1: Handling paper at the occurrence of a paper feed timing error (Not used.)
When feeding paper to the print start position, the machine might cause a feed timing error so that
the registration sensor goes ON signaling the presence of paper. This selector determines whether
the machine prints on the current paper or ejects the current paper without printing and prints on
the next paper.
- Selectors 3 and 4: Delay of FAX line disconnection when switching to the pseudo-ringing external
telephone (Not used.)
When the machine receives a phone call, it can make the connected external telephone ring (so
called pseudo-ringing). During pseudo-ringing, if you pick up the handset of the external
telephone, the line might be disconnected due to cut-off of the line current.
To hold the line, the machine may supply line current by making use of the pulse generator circuit
that forms a parallel loop. This way the FAX line disconnection may be delayed. These selectors
determine the delay period.

Brother DCP-8065DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	32 MB
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Mac OS X 10.2.4 or greater Windows XP
Standard interfaces	USB 2.0
Sustainability certificates	ENERGY STAR
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	660 W
