6-22 Confidential
(9) Install the FU harness cover 2.
Fig. 6-38
(10) Install the Heater terminal L and Heater terminal S.
Fig. 6-39
FU harness cover 2
Hook
9a
9b
Heater terminal L
Heater terminal S
Fuser unit
