Brother DCP-8065DN

6-36 Confidential
(2) Put the Pin of the Roller holder ASSY into the hole of the Lift arm.
(3) Place the Machine on its base.
Fig. 6-66
(4) Install the DX feed ASSY or DX blank cover.
Fig. 6-67
Lift arm
Pin
Machine
Roller holder ASSY
2a
2b
DX feed ASSY/ DX blank cover
