Troubleshooting and routine maintenance
163
C
h Put the toner cartridge back firmly into
the drum unit until you hear it lock into
place.
Note
Make sure that you put in the toner
cartridge correctly or it may separate from
the drum unit.
i Slide each drum unit and toner cartridge
assembly into the machine. Make sure
that you match the toner cartridge colour
to the same colour label on the machine.
C-Cyan M-Magenta Y-Yellow K-Black
j Close the top cover of the machine.
k Plug the machine’s power cord back into
the electrical socket first, and then
reconnect all cables and telephone line
cord. Turn on the machine.
h
K
Y
M
C
