BRP EVINRUDE E-TEC 150 HP 2011 - Oiling System Circuit Diagram

OILING SYSTEM
OILING SYSTEM CIRCUIT DIAGRAM
159
8
OILING SYSTEM CIRCUIT DIAGRAM
007094
12
1
9
4
8
1 2
1 2
3
6
5
4
J2
J1-B
J1-A
1
2
3
4
5
2
1 2 3 4 5 6 7 8 9
18 19 20 21 22 23 24 25
26 27 28 29 30 31 32 33 34
1 2 3 4 5 6 7 8 9 10
11 12 13 14 15 16 17 18 19
1 2 3 4 5 6 7
8 9 10 11 12 13
10 11 12 13 14 15 16 17
14 15 16 17 18 19
20 21 22 23 24 25 26
20 21 22 23 24 25 26 27 28 29
3
5
6
7
10
11
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
Oil Injection Pump
EMM
55 V Circuit (WHITE/RED)
Grounds, NEG (BLACK)
EMM to Oil Solenoid (BLUE)
Oil Pressure Sensor, +5 V analog (RED)
Oil Pressure Sensor Signal (TAN/WHITE)
Capacitor
Low Oil Switch
Low Oil Signal
No Oil Signal
SystemCheck Connector
