BRP EVINRUDE E-TEC 150 HP 2011 - Exhaust Housing Disassembly - V4 Models; Exhaust Housing Disassembly - V6 Models

244
MIDSECTION
EXHAUST HOUSING SERVICE
Exhaust Housing Disassembly –
V6 Models
Remove the front and rear screws retaining the
adapter/inner exhaust housing to the exhaust
housing.
Lift the adapter/inner exhaust housing out of the
exhaust housing.
Remove the water tube. Inspect water tube grom-
met and replace if necessary.
Exhaust Housing Disassembly –
V4 Models
Remove three screws and exhaust valve actuator.
Remove collar only if replacing exhaust housing.
Loosen collar screw. Remove collar.
IMPORTANT: Do NOT remove exhaust valves
they are not serviceable.
1. Adapter retaining screws 005205
005207
1. Water tube grommet 005210
1
1
1
1. Actuator screws 007182
1. Screw
2. Collar
007185
1
1
2
1
