300
GEARCASE – STANDARD ROTATION
GEARCASE ASSEMBLY
Install new seals in driveshaft bearing housing.
Refer to Driveshaft Bearing Housing Service on
p. 290. Using Driveshaft Seal Protector,
P/N 318674, slide the driveshaft bearing housing
onto the driveshaft.
Apply Gasket Sealing Compound to the threads of
the driveshaft bearing housing screws. Tighten
screws in stages to a torque of 120 to 144 in. lbs.
(13.5 to 16.5 N·m).
Upper Driveshaft Installation 005428
1. Seal protector COA3130
1. Driveshaft bearing housing screws 005425
