BRP SUMMIT - Page 111

Section 03 ENGINES
Subsection 05 (TOP END)
593 HO SDI Engine
A33C2R S
25
27
26
25
Engine
oil
Loctite 518
16
15
5.5 Nm
(49 lbfin)
5.5 Nm
(49 lbfin)
16
3
1.5 Nm
(13 lbfin)
9 Nm
(80 lbfin)
5.5 Nm
(49 lbfin)
Multi-purpose
grease
24
40 Nm
(30 lbfft)
22
7.5 Nm
(66 lbfin)
40 Nm
(30 lbfft)
23
2
11
9
6
8
12
Engine oil
5
13
5.5 Nm
(49 lbfin)
Sealing
compound
Drei Bond
5.5 Nm
(49 lbfin)
9 Nm
(80 lbfin)
7.5 Nm
(66 lbfin)
23 Nm
(17 lbfft)
29 Nm
(21 lbfft)
29 Nm
(21 lbfft)
Sealing
compound
Drei Bond
20
21
1
19
21
21
29 Nm
(21 lbfft)
28
4
7
14
10
3 Nm
(27 lbfin)
29
mmr2005-072 95
