Proton Spectrum
H171804E_14_001 59 / 86
Shim the sample
• On the Workflow button bar, click Shim.
This executes the command topshim. The shimming starts momentarily and should take less
then a minute. On the Shim button, click the drop-down arrow to see more options.
Load the prosol parameters
• On the Workflow button bar, click Prosol.
This will load the pulse widths and power levels into the parameter set.
8.2 Acquisition
Set the receiver gain
• On the Workflow button bar, click Gain.
or
• On the Gain button, click the drop-down arrow to adjust the receiver gain manually.
Start the data acquisition
• On the Workflow button bar, click Run.
or
• On the Run button, click the drop-down arrow to see more options.
8.3 Processing
• When the acquisition has finished, click Process on the menu bar.
• On the Proc Spectrum button, click the drop-down arrow to see more options.
• In the list, select Configure Standard Processing (proc1d).
• In the proc1d window, enable the following options:
– Exponential Multiply (em)
– Auto - Phasing (apk)
– Auto - Baseline Correction (absn)
