30 (93) BRUKER CryoProbe Installation
Initial setup
m.9 WARNING: While mounting the CryoProbe, the magnet must not be
suspended on its anti-vibration feet.
WARNING: Do not attempt to insert or remove the heavy CryoProbe
(~12 kg) at the magnet without the help of a second person. You may
easily injure your back when lifting the CryoProbe on your own!
Remove the protective cap from the top of the CryoProbe.
Move the CryoProbe carefully from the magnet front to below the bore.
Do not let it rub on the floor or on the cranked pillar brace (Figure 3.5.
).
Let its body touch the two long guiding rails that extent downward
from the Mounting Hardware.
m.10 Align the CryoProbe top with the shim system bore.
Push it gently up into the magnet until the support plate can be
snapped into the notched guiding rails.
Snap the support plate into place. Verify correct seat of all four support
points.
IMPORTANT: While sliding it carefully into the magnet, prevent bend-
ing of the CryoProbe tube by keeping it close to the rails - but do not
press it against them. Do not use any extra force to push it up, it should
slide without resistance.
