CryoProbe Installation BRUKER 75 (93)
Check lists A
1000000
Site preparation checks 1.1
Before an installation date with BRUKER is fixed, the customer has to make sure
that the following prerequisites are fulfilled in the NMR laboratory.
❢ Can the CryoProbe System be installed according to the site planning that was
agreed on with B
RUKER or did something change in the meantime? If yes, con-
tact B
RUKER immediately!
❢ Are all supplies available (mains, pneumatic gas, cooling water...)?
❢ Do all supplies carry the required connectors?
❢ Do other devices in the laboratory depend on the same supplies as the
CryoProbe - in particular: pneumatic gas and electricity? Is there a need for
gas buffers, check valves, or a UPS? Can the other laboratory equipment con-
tinue its operation during the CryoProbe installation or does it have to be
switched off?
❢ Is the path for all cables and tubes associated with the CryoProbe System pre-
pared (space, cable channels, holes...)?
❢ Is the space below the magnet between shim system bottom plate and floor
cleared?
❢ Is the acoustic insulation for the He Compressor and the optional water chiller
ready (adjacent room or cabinet)?
❢ Is there enough space for delivery, unpacking, and installation? Is a hoist avail-
able for unpacking the CryoCooling Unit?
❢ Will a second person be occasionally available to lift the heavy CryoProbe into
the magnet?
❢ Is a recent set of NMR reference data available that can document the spec-
trometer performance, e.g. in terms of lineshape, sensitivity, stability, spurious
signals etc.?
Preparations for the installation visit 1.2
When planning and preparing an actual CryoProbe installation, the Bruker office
must consider the following points.
❢ Have all CryoProbe System parts been shipped?
❢ Are all required tools at hand?
❢ Are the latest versions of the CryoProbe System documents and software
available, e.g. Installation, Site Planning and User manuals, Firmware and
CryoTool?
