46 (93) BRUKER CryoProbe Installation
Initial setup
Put a label on or next to the holder of the He steel-cylinder. If the He Compressor
or the optional water chiller are in the same room as the NMR magnet, label them
also. They are on wheels and therefore potentially mobile.
Connecting 3.18
0
Table 3.11. Connect the CryoProbe
step action
j.1 Plug the two sensor cables from the CryoCooling Unit into the Cryo-
Probe bottom and into J2 on the front, respectively. Connect the Cryo-
Preamp supply cable from the HPPR CRP to J1.
j.2 Connect the VT sensor cable and the VT gas hose to the probe bot-
tom. Check if all connections for the VT Interface Box are properly
made. At the VT unit, e.g. B-VT3000, the Pt100 sensor must be
selected. The reading in edte should indicate room temperature.
j.3 Attach the Tuning Adapter (Figure 3.14.
) to the CryoProbe bottom.
Use the blue Tuning Tool to lock its mounting screws.
NOTE: There are specific Tuning Adapters for each type of CryoProbe.
Figure 3.13. Strong attraction by magnet!
The item is magnetic and presents a potential hazard in the vicinity of
a magnet. Keep it away from the magnet!
!
