Basic Operation VÅNTEC-1 Detector User Manual
9 - 4 M88-E01072
9.4 Disconnecting the Power Plug
To remove, relocate or service the detector con-
troller, it may be necessary to disconnect the
power cord from the rear of the controller.
1. Ensure that all power is off to the enclosure
prior to removing the power cord.
2. Remove the rear access panel of the D8
enclosure. Use caution when removing the
panel as the ventilation fans are connected
to it.
3. Visually inspect the power cord for frayed or
exposed wiring prior to removal. If the
power cord appears defective, contact
Bruker AXS Service for replacement by
qualified service personnel.
4. With the access panel removed, firmly
grasp the power cord of the detector con-
troller at the strain relief and pull the cord
from the controller.
5. The power cord is connected to X601 on the
left side of the D8 enclosure. Pull the plug
from this outlet strip.
9.5 Lock Out
1. Use the key located on the left side column
of the D8 enclosure to lock and unlock the
system.
During normal operation, the key must be
switched to the unlocked position. In the
unlocked position, power may be applied with
the ON button located on the right-hand column
of the D8 enclosure. In the locked position, no
power will be available for the control electron-
ics, generator or X602 connectors. The key can
only be removed in the locked position.
Power will still be present at the X601
connectors. Electric shock can result if proper
safety precautions are not observed.
