Appendix C: Updating the Detector Controller Firmware VÅNTEC-1 Detector User Manual
C - 6 M88-E01072
7. Choose the Browse button and select the
update package with the extension *.tgz .
NOTE: Update vs. Complete (Re)Installation:
The “Update” variant (recommended) leaves
intact all configuration files stored on the Flash
drive, whereas “Complete (Re)Installation” for-
mats the Flash drive before installing, discarding
all configuration files.
8. Press the Proceed button to begin the
update process. It should take about one
minute.
9. When finished, a report about the installa-
tion process will be displayed.
10. The update of the PSDWARE is now com-
plete.
11. To activate the update, reboot the detector
controller by switching it off, waiting 5 sec-
onds, and switching it on again. After reboo-
ting, the detector controller should be
reachable with your Web browser at the
same IP address.
C.3 Updating the FPGA Firmware
1. To update the FPGA firmware, access the
detector controller with a Web browser as in
the first part of Section C.2. At the detector
controller menu, select the Update FPGA
of TDC link. The Update page will appear
on the right side of the window.
Figure C.10 - Updating FPGA firmware
