M88-E01072 6 - 1
6. Software Configuration
This section describes basic software configura-
tion.
Communications between the D8 controller,
FDC (if present) and the detector are made via
RS232 communication ports. Communications
between the frame buffer computer and the
detector controller are made via a network con-
nection. The parameters for communications
must be defined by the user and are stored in
the device.ini file. The Configuration program is
used to set the parameters. Perform the follow-
ing steps to configure the system (see Figure
4.3 for the cabling scheme for an internal FDC,
Figure 4.6 for the cabling scheme for an inte-
grated FDC).
6.1 Recommendations
Software versions listed are minimum recom-
mended versions.
D8 Controller Firmware 2.03
D4 Controller Firmware 1.05
PSDWare 0.51
FPGA v1.01 AK (for external FDC)
FPGA v1.02 AN (for internal FDC)
DIFFRAC
plus
Measuring Package
VÅNTEC-1 Update Package
Clock Signal Cable A17-D42
Adapter for Clock Signal Cable A17-D43
NOTE: Never mix software packages/versions
from VÅNTEC update CDs containing different
releases!
