Bruker VANTEC-1 - Set up Communication Parameters (both FDC Types)

Software Configuration VÅNTEC-1 Detector User Manual
6 - 10 M88-E01072
6.5.3 Set Up Communication Parameters
(both FDC types)
Under Diffractometer, select Settings.
1.1 In the pop-up window, select TCP/IP as
the connection type.
1.2 Enter the IP address 192.168.23.2 and
the port 4251.
1.3 Click OK and close the window.
Figure 6.10 - Diffractometer > Settings pop-up window
2. In Computer Ports, select Settings under
PSD Controller.
2.1 In the pop-up window, under TCP/IP,
enter the IP address 192.168.23.2 and
the port 4250.
2.2 Click OK and close the window.
Figure 6.11 - PSD Controller > Settings pop-up window
3. In Computer Port Configuration, click OK to
accept the changes (see Figure 6.8).
4. To activate the configuration, go to File >
Save and Download or click the CNF icon.
