VÅNTEC-1 Detector User Manual System Description
M88-E01072 3 - 5
3.1.2 Environmental Ratings
Table 3.2 shows the range of environmental
conditions for which the equipment is designed.
Table 3.2 – Environmental ratings of the detector
3.2 The Detector Controller
The detector controller currently has the FDC
integrated within the detector controller. Previ-
ous configurations have an external FDC unit.
Both configurations are discussed in this man-
ual.
3.2.1 Identifying Integrated and External
FDC configurations
Older detector controllers contain the electronic
circuit boards for signal processing, the detector
(high-voltage) power supply, a power supply for
the detector preamplifiers, the Constant Fraction
Discriminator (CFD) boards, the Time to Digital
Converter (TDC) boards, and all electronic
assemblies. All of these units are placed within
the same 19" housing as shown in Figure 3.4.
In these older configurations, the FDC is an
external unit.
Newer detector controllers have FDC controller
integrated within the detector controller chassis.
Ambient temperature 41–104°F (5–40°C)
Operating temperature 57–93°F (14–34°C)
Maximum temperature
gradient
+
0.9°F (+ 0.5°C) per hour
Relative humidity Max 80%, non-condensing,
for temperatures up to
88°F (31°C) decreasing
linearly to 50% at 104°F
(40°C)
Location of use Indoor
Altitude Up to 1.2 miles (2000 m)
Mains supply voltage
fluctuations
Up to +
10% of the nominal
voltage
Overvoltage category IEC 664 II
CE certification See Appendix D
Pollution degree 2
