VÅNTEC-1 Detector User Manual Appendix B: Spare Parts List
M88-E01072 B - 3
A17B17 Debye slit 4 mm
A17B18 Ni filter for Cu-Kβ radiation for VÅNTEC-1 (high overall intensity), 2.5%
A17B19 Debye slit 1 mm
A17B20 Fe filter for Co-Kβ radiation for VÅNTEC-1
A17B21 V filter for Cr-Kβ radiation for VÅNTEC-1
A17B22 Zr filter for Mo-Kβ radiation for VÅNTEC-1
A17B23 Ni filter for low Cu-Kβ radiation for VÅNTEC-1 (default), 0.5%
A17B25 Soller slit 2.5° for VÅNTEC-1
A17B26 Soller slit 4° for VÅNTEC-1
A17B27 Air scatter screen, 401 mm diameter
A17B28 Air scatter screen, 435 mm diameter
A17B29 Air scatter screen, 500 mm diameter
A17B30 Beam Stop for D8 (150 mm goniometer height)
A17B31 Long anti-scatter slit assembly (500 mm measurement circle)
A17B32 Beam Stop for D4
A17B35 Mount for VÅNTEC-1, measurement height 150 mm
A17B36 Mount for VÅNTEC-1, measurement height 214 mm
A17B37 Mount for VÅNTEC-1, measurement height 258 mm
Part Number Description
Table B.1 – Spare parts
