VÅNTEC-1 Detector User Manual Hardware Installation for the D8 ADVANCE

M88-E01072 4 - 29

Figure 4.29 - Alignment of the paddle using the

fluorescent screen

Tilt

adjustment

Paddle

2 mm gap
