Work of service (DADF)
When replacing the parts
This machine has the following adjustment items. Carry out each adjustment after replacing
the relevant parts.
Adjustment type Parts to replace Remarks Reference
Height adjustment Hinge Refer to page
5-3
Perpendicularity adjustment Hinge
Refer to page
5-6
Reading position adjustment Platen roller
Refer to page
5-7
Side registration adjustment - During installation only
Refer to page
5-7
Trailing edge registration adjustment - During installation only
Refer to page
5-7
Magnication adjustment Motor/roller
Refer to page
5-7
White level position adjustment Platen roller
Refer to page
5-8
Caution:
Carry out all the above adjustments after removing the DADF from the reader unit.
T-3-3
Periodic Servicing
When the parts are reaching the expected service life, perform the parts replacement or
cleaning etc if needed.
Item Part name Expected
service life
Operation Reference
Periodically replaced
parts
No - - -
Durables parts Pickup roller unit 80,000 sheets Replace-
ment
Refer to page
4-16
Separation pad
Refer to page
4-17
Stamp 7,000 times
Refer to page
4-17
Feed guide (dust collection tape) 40,000 sheets
Refer to page
4-18
Periodically serviced
parts
Pickup roller unit 40,000 sheets Cleaning -
Separation pad -
Upper registration roller -
Lower registration roller -
Upper delivery reversal roller -
Lower delivery reversal roller -
Various rollers/driven rollers -
Various scrapers -
ADF height adjustment Adjustment
Refer to page
5-3
T-3-4
