Signal Name List(DADF)
■
Signal Name List
Jack No. Pin No Abbreviated Signal Name Signal Name
J1 1 +5V
2 GND
3 REG SENS Registration sensor signal
4 +5V
5 GND
6 READ SENS Read sensor signal
7 +5V
8 GND
9 EXIT SENS Delivery reversal sensor signal
10 Unused
J2 1 +5V
2 GND
3 TIMING SENS Timing sensor signal
4 +5V
5 GND
6 EMPTY SENS Document set sensor signal
7 +5V
8 GND
9 COVE SENS Cover open/closed sensor signal
J3 1 +5V
2 GND
3 SIZE L1 SENS Document length sensor 1 signal
4 SIZE L2 SENS Document length sensor 2 signal
5 LAST SENS Last document detection sensor signal
6 SIZE W1 SENS Document width sensor 1 signal
7 SIZE W2 SENS Document width sensor 2 signal
8 Unused
J4 1 ADF-MOT /A ADF motor A*
2 BCOM (24V)
3 ADF-MOT /B ADF motor B*
4 ADF-MOT A ADF motor A
5 ACOM (24V)
6 ADF-MOT B ADF motor B
J5 1 +5V
2 GND
3 RKMOT HP SENS Release motor HP sensor signal
4 24V
5 STMP CL Stamp solenoid signal
6 +5V
7 SET LED Document detection LED signal
8 Unused
J6 1 24V
2 RIKAN SOL Pressurization solenoid signal
J7 1 24V
2 PICK CL Pickup clutch signal
3 24V
4 REG CL Registration clutch signal
J8 1 24V
2 GND
3 FAN LOCK FAN lock signal
J9 1 +5V
2 GND
3 RKMOT HP SENS Release motor HP sensor signal
4 COVER SENS Cover open/closed sensor signal
5 EMPTY SENS Document set sensor signal
6 XEIT SENS Delivery reversal sensor signal
7 TIMING SENS Timing sensor signal
8 REG SENS Registration sensor signal
9 READ SENS Read sensor signal
10 LAST SENS Last document detection sensor signal
11 Unused
J10 1 ADFMOT CLK ADF motor clock signal
2 ADFMOT CWB ADF motor CWB signal
3 ADFMOT ENB ADF motor ENB signal
4 GND
5 RKMOT STEP Release motor STEP signal
6 RKMOT FR Release motor FR signal
7 RKMOT OE Release motor OE signal
8 GND
9 RKMOT VREF Release motor VREF signal
10 GND
11 ADFMOT PWM ADF motor PWM signal
12 RKMOT STB Release motor STB signal
13 RKMOT SOL Pressurization solenoid signal
14 STMP SOL Stamp solenoid signal
15 PICK CL Pickup clutch signal
16 REG CL Registration clutch signal
17 SET LED Document detection LED signal
18 GND
19 FAN FAN signal
20 FAN LOCK FAN lock signal
21 GND
22 SIZE W1 Document width sensor 1 signal
23 SIZE W2 Document width sensor 2 signal
24 SIZE L1 Document length sensor 1 signal
25 SIZE L2 Document length sensor 2 signal
