Appendix > Signal Name List(Reader)
Appendix > Signal Name List(Reader)
J11 1 24V
2 GND
J12 1 RK-MOT A Release motor A
2 RK-MOT A Release motor A*
3 RK-MOT B Release motor B
4 RK-MOT /B Release motor B*
5 Unused
J50 1 SIZE W1 SENS Document width sensor 1 signal
2 SIZE W2 SENS Document width sensor 2 signal
3 LAST SENS Last document detection sensor signal
4 SIZE L2 SENS Document length sensor 2 signal
5 SIZE L1 SENS Document length sensor 1 signal
6 GND
7 +5V
J51 1 +5V
2 GND
3 LAST SENS Last document detection sensor signal
4 +5V
5 GND
6 SIZE L2 SENS Document length sensor 2 signal
7 +5V
8 GND
9 SIZE L1 SENS Document length sensor 1 signal
T-7-3
