List of Parts(Reader)
External Covers
No. Name Part No. Refer to
1 Reader Front Cover - Refer to page 4-3
2 Reader Front Sub Cover - -
3 Reader Left Cover -
Refer to page 4-3
4 Reader Rear Cover -
Refer to page 4-4
5 Reader PCB Cover - -
6 Rear Small Cover - -
7 Reader Right Cover -
Refer to page 4-3
Main Units
No. Name Part No. Refer to
8 CCD Unit FM4-7540 Refer to page 4-5
9 Copyboard Glass FL3-3592
Refer to page 4-8
10 Stream read Glass FL3-3206
Refer to page 4-9
List of Clutchs, Solenoids, Motors, Fans, PCBs
No. Name Part No. Refer to
M1 Scanner motor - -
PCB1 Relay Board - -
List of Sensors
No. Name Part No. Refer to
SR1 CCD HP Sensor - -
SR2 Copyboard Cover Open/Closed Sensor (rear) - -
SR3 Copyboard Cover Open/Closed Sensor (Front) - -
SR4 Original Size Sensor 0 - -
SR5 Original Size Sensor 1 - -
T-4-1
T-4-2
T-4-3
T-4-4
[1]Reader Front Cover
[2]Reader Front Sub Cover
[3]Reader Left Cover
[7]Reader Right Cover
[5]Reader PCB Cover
[4]Reader Rear Cover
[10]Stream Read Glass
[9]Copyboard Glass
[6]Rear Small Cover
[M1]Scanner Motor
[SR4]Original Size Sensor 0
[PCB1]Relay Board
[SR2]Copyboard Cover
Open/Closed Sensor(Rear)
[SR3]Copyboard Cover
Open/Closed Sensor(Front)
[SR1]CCD HP Sensor
[8]CCD Unit
[H5]Reader Heater(Option)
[H5]Reader Heater(Option)
[SR5]Original Size Sensor 1
Consumable Parts Requiring Periodic Replacement
and Cleaning Points
None
F-4-1
F-4-2
