Carel WB000DG0F0 User Manual

57
ENG
UltraCella +0300083EN - rel. 1.5 - 07.02.2015
Par. Description Def Min Max UOM Type CAREL SVP Modbus
SVP
R/W page
PrE Main regulation type
1 centralized cabinet cold room 3 perturbated cabinet cold room
2 self contained cabinet cold room 4 subcritical co2 cabinet/cold room
2 1 4 - I 137 148 R/W 39
P0 EVD Modbus address 198 1 247 - I 134 145 R/W 39
P3 Superheat setpoint 10 -72 324 K
A 44 35 R/W 39
P4 Proportional gain 15 0 800 -
A 36 27 R/W 39
P5 Integral time 150 0 999 sec
A 148 159 R/W 39
P6 Derivative time 2 0 800 sec
A 37 28 R/W 39
P7 LowSH: threshold low superheat 3 -72 324 K
A 45 36 R/W 39
P8 Low Superheat protection integral time 600 0 800 sec
A 38 29 R/W 39
P9 LowSH: low superheat alarm delay 600 0 999 sec
A 150 161 R/W 39
PL1 LOP: threshold for low temperature of evaporation -50 -76 392 °C/°F
A 64 41 R/W 39
PL2 LOP: integral time 600 0 800 sec
A 39 30 R/W 39
PL3 LOP: low evaporation temperature alarm delay 600 0 999 sec
A 151 162 R/W 39
cP1 Open valve startup, Percentage 50 0 100 %
A 146 157 R/W 39
Pdd Post defrost delay, only for single driver 10 0 60 min
A 147 158 R/W 39
PSb Valve position in stand-by 0 0 100 step
A 169 174 R/W 39
PMP Enable manual positioning 0 0 1 -
D 103 38 R/W 39
Pnr Reset EVD setting 0 -> 1 Reset all EVD parameters 0 0 1 -
139 46 39
Ultra 3PH Module commissioning
cH1 3PH module serial address 1 1 247 - I 185 177 R/W 39
40
cH2 3PH module off set serial address 0 0 232 - I 186 178 R/W 39
40
cH3 Type of three phase module
0 = Evaporator
1 = Full
0 0 1 - I 187 179 R/W 39
40
cA1 Sd1 probe connection
0 = in UltraCella
1 = in 3PH module
0 0 1 - D 130 40 R/W 39
40
cA2 Sd2 probe connection
0 = in UltraCella
1 = in 3PH module
0 0 1 - D 131 41 R/W 39
40
cA3 Sc probe connection
(Full module only)
0 = in UltraCella
1 = in 3PH module
0 0 1 - D 132 42 R/W 39
40
cEn Enable 3PH mod.
0 = disable
1 = enable
0 0 1 - D 133 43 R/W 39
40
HACCP alarms (MULTIFUNCTION MENU)
HA Date/time of last HA alarm: day - 1 7 day I 72 29 R 61
Date/time of last HA alarm: hour - 1 23 hour I 73 30 R 61
Date/time of last HA alarm:minute - 1 59 min I 74 31 R 61
HA1 Date/time of second last HA alarm: day - 1 7 day I 75 32 R 61
Date/time of second last HA alarm: hour - 1 23 hour I 76 33 R 61
Date/time of second last HA alarm:minute - 1 59 min I 77 34 R 61
HA2 Date/time of third last HA alarm: day - 1 7 day I 78 35 R 61
Date/time of third last HA alarm: hour - 1 23 hour I 79 36 R 61
Date/time of third last HA alarm:minute - 1 59 min I 80 37 R 61
HAn Number of HA alarms - 1 15 - I 96 53 R 61
HF Date/time of last HF alarm: hour - 1 7 day I 81 38 R 62
Date/time of last HF alarm: hour - 1 23 hour I 82 39 R 62
Date/time of last HF alarm:minute - 1 59 min I 83 40 R 62
HF1 Date/time of second last HF alarm: day - 1 7 day I 86 43 R 62
Date/time of second last HF alarm: hour - 1 23 hour I 87 44 R 62
Date/time of second last HF alarm:minute - 1 59 min I 88 45 R 62
HF2 Date/time of third last HF alarm: day - 1 7 day I 91 48 R 62
Date/time of third last HF alarm: hour - 1 23 hour I 92 49 R 62
Date/time of third last HF alarm: minute - 1 59 min I 93 50 R 62
HFn Number of HF alarms - 1 15 - I 97 54 R 62
Hcr Reset HACCP alarms (1 = reset) 0 0 1 - D 23 12 R/W 62
Tab. 7.a
