Carel WB000DG0F0 User Manual

56
ENG
UltraCella +0300083EN - rel. 1.5 - 07.02.2015
Par. Description Def Min Max UOM Type CAREL SVP Modbus
SVP
R/W page
HO1 Output Y1 confi guration
0 Not active
1 Do not select
2 Variable speed evaporator fans set on Sd probe
0 0 2 - I 63 102 R/W 42
47
48
tr1 First temperature to be recorded
0 No log 4 Sd1
1Sv 5 Sd2
2Sm 6 Sc
3Sr 7 SA
0 0 7 - I 189 181 R/W 29
tr2
Second temperature to be recorded
0 No log 4 Sd1
1Sv 5 Sd2
2Sm 6 Sc
3Sr 7 SA
0 0 7 - I 190 182 R/W 29
trc Sample time temperature recording 5 2 60 min I 191 183 R/W 29
HcP
HCE Enable HACCP
0/1 = No/Yes
0 0 1 - D 22 11 R/W 61
Htd HACCP alarm delay 0 0 250 min I 71 110 R/W 61
rtc
tcE Enable data modifi cation 0/1 = no/ yes 0 0 1 - D 24 13 R/W 23
tcT Date/ time change
Action on variation 01 o 10
0 0 1 - D 25 14 R/W 23
y__ Date/ time: year 0 0 37 - I 98 111 R/W 23
M__ Date/ time: month 1 1 12 - I 99 112 R/W 23
d__ Date/ time : day of month 1 1 31 - I 100 113 R/W 23
h__ Date/ time: hour 0 0 23 - I 101 114 R/W 23
n__ Date/ time: minute 0 0 59 - I 102 115 R/W 23
tcL Hours/minutes visualization on the second row for models with two rows
display 0/1=no/yes
0 0 1 - D 72 29 R/W
ddi Defrost i (i=1…8): day 0 0 11 day I 103…110 116...123 R/W 45
hhi Defrost i (i=1…8): hour 0 0 23 hour I 111…118 124...131 R/W 45
nni Defrost i (i=1…8): minute 0 0 59 min I 119…126 132...139 R/W 45
doL
c12 Compressor safety time for door switch
0 = disable door management
5 0 5 min I 64 103 R/W 36
d8d Compressor restart time for door switch 30 0 240 min I 65 104 R/W 36
A3 Disable door microswitch
0 = door microswitch enabled
1 = door microswitch disabled
0 0 1 - D 138 45 R/W 34
tLi Light on with door open 120 0 240 min I 66 105 R/W 37
A4 Light management
0 = door switch + light key - 1 = light key
0 0 1 - D 18 7 R/W 37
rcP (see charter 3 the procedure for setting parameters to default values)
Eud
P1 Enable communication with Evd module
0/1=no/yes
0 0 1 - D 70 27 R/W 39
P1t S1 probe type
0 RAZ. 0-5V 2 4-20mA REMOTE
1 4-20mA 3 4-20mA EXTERNAL
0 0 3 - I 139 150 R/W 39
P1M Max value of S1 probe 12,8 -20 200 °C/°F A 31 22 R/W 39
P1n Min value of S1 probe -1 -20 200 °C/°F A 30 21 R/W 39
PVt Valve type
1 Carel exv 12 Sporlan seh 100
2 Alco ex4 13 Sporlan seh 175
3 Alco ex5 14 Danfoss ets 12.5 - 25b
4 Alco ex6 15 Danfoss ets 50b
5 Alco ex7 16 Danfoss ets 100b
6 Alco ex8 330hz carel recommended 17 Danfoss ets 250
7 Alco ex8 500hz alco specifi cation 18 Danfoss ets 400
8 Sporlan sei 0.5-11 19 two Carel exv connected
together
9 Sporlan ser 1.5-20 20 Sporlan ser(i) g, j, k
10 Sporlan sei 30 21 Danfoss ccm 10-20-30
11 Sporlan sei 50 22 Danfoss ccm 40
1 1 22 - I 136 147 R/W 39
PH Refrigerant type
0 R22 5 R507A 10 R744 15 R413A 20 R245Fa
1 R134a 6 R290 11 R728 16 R422A 21 R407F
2 R404A 7 R600 12 R1270 17 R423A 22 R32
3 R407C 8 R600a 13 R417A 18 R407A 23 HTR01
4 R410A 9 R717 14 R422D 19 R427A 24 HTR02
2 0 24 - I 135 146 R/W 39
