4-OPERATINGINSTRUCTIONS
Turningtotheright(reversetravel)
Simplypresstheleft-handpedalortheleft-handlever
rearwards.
SMIL13CEX2684AB8
Turningonthespot,totheright
Presstheleft-handpedalortheleft-handleverforwards
andatthesametimepresstheright-handpedalorthe
right-handleverrearwards.
SMIL13CEX2685AB9
Turningonthespot,totheleft
Presstheright-handpedalortheright-handleverfor-
wardsandatthesametimepresstheleft-handpedalor
theleft-handleverrearwards.
NOTE:Turningonthespotcannotbedoneifhighspeed
travelisselected.
SMIL13CEX2686AB10
Gradualturnonthemove
Pressoneofthepedalsoroneoftheleversand,atthe
sametime,presstheotherpedalortheotherleverinthe
samedirection,butslightlyharder.
Stoppingtravel
Tocometoacompletehalt,simplyreleasetheleversor
pedalsandtheywillreturntoneutral.
SMIL13CEX2687AB11
4-13
